VECTRONIC 2KVA LINE INTERACTIVE UPS

Product specifications:

Input

Voltage230 Vac

Tolerance Normal Over-voltage:       10%

Withstand Over-voltage:   15% (20% max limit)

 Normal Under-voltage:      – 20%

Withstand Low-voltage:      – 30% (-37% lowest limit)

Power Factor0.98

Output

Voltage     230Vac ± 1%

Power Factor0.8

 0.9

Transfer Time    0 ms

Frequency46 – 54Hz (On Mains)

 50Hz (On Battery)

Waveform                     Pure Sine Wave

THDiLinear Load ≤ 3%;     Non-linear Load ≤ 6%

Crest Factor 3 : 1

Bypass FacilityFS Model:       Static Bypass

 FS-V Model:   Both Maintenance Bypass and Static Bypass

DC Bus / DC Functions:

1kVA36V

2kVA72/96V

3kVA96V

6/10kVA192V / 240V

Cold-Start FunctionYes

Charging Time  6hr to recover to 90% capacity

Battery Charging in OFF Mode   Yes

Battery TypeSealed, Maintenance-free VRLA

LCD User Interface:

Metering / Indications forVoltage

 Load %

Frequency

 General Status

Alarm

Communication:

Interfaces RS232, USB*, SNMP*                          (* Option)

Overload

100~110%Output swithes to bypass after 60s

125~130%Output swithes to bypass after 30s

 >130%Output swithes to bypass after 100ms

Environment:

Temperature      0 ~ 40oC

Humidity      20 ~ 90% Non-condensing

Noise Level             < 50dB from 1m

IP Class20

Physical:

Dimensions  (mm)        1kVA      :       145 x 405 x 220 (W x D x H)

 2-3kVA   :       192 x 460 x 340 (W x D x H)

6-10kVA :       248 x 500 x 460 (W x D x H)

Weight (Kg)1kVA      :       14kg

 2kVA      :       34kg

 3kVA      :       34.5kg

 6kVA      :       57kg / 192V:          90kg / 240V

 10kVA    :       60kg / 192V;          93kg / 240V
